| TECHNICAL PARAMETERS | |
| |
| Controlling Characteristic |
| Starting Torque | 0.5Hz100% |
| Speed Adjustable Range | 0.111111111 |
| Speod-holding precision | ±1.0% |
| Overload Capability | 150% rated current for 60s |
| 180% rated current for 1s |
| Acceleration/deceleration Time | 0.1-3600s |
| |
| Input&Output Parameters |
| Starting Frequency | 0.01~10.00Hz |
| Input Voltage | 220V/380±15% |
| Input Frequency Range | 50/60Hz,fluctuation±5% |
| Output Voltage | 0-rated input voltage |
| Output Frequency | 0-200Hz |
| |
| Peripheral Interface |
| Programmable Digital Input | 2 way of digital terminal input |
| Programmable Analog Input | V:0-5V |
| V(remote pressure gauge):0-10V |
| C (pressure transducer ):4-20mA |
| Replay Output | 1 way output,pragrammable |
| Open Collection Output | 1 way output,pragrammable |
| |
| Use Condition |
| Installation | Installation should be executed under the conditions of no direct sunlight,dust,corrosive gas,inflammable gas,oil mist,steam and water drop |
| Altitude | Lower than 1000m, service in derated capacity above 1000m.Derate 1% capacity every 100m increase in temperature |
| Environment Temperature | -10℃-+40℃,service in derated capacity for 40℃-50℃.Derate 4% capacity every 1℃ increase in height |
| Humidity | ≤95%RH,no water condensation. |
| Vibration | <5.9m/52(0.6G) |
| |
